Figure 2: Remove the Drive
Release button2Ejector handle1
Step 2 Remove the four drive-tray screws that secure the drive to the tray and then lift the drive out of the tray.
Figure 3: Remove the Drive Tray
Maintenance and Upgrade
6
Maintenance and Upgrade
Remove and Replace a Drive
