The TGSH Dialog is displayed on the console when the server has successfully booted up and connected.
Figure 7: TGSH Dialog
The Admin URL shows as unavailable because the network interface connections are not yet configured and
the OpAdmin Portal cannot be reached yet to perform this task.
The TGSH Dialog displays the initial administrator Password, which will be needed to access and configure
the OpAdmin Portal interface later in the configuration. Make a note of the Password in a separate text file
(copy and paste).
Important
Server Setup
9
Server Setup
Power On and Boot Up Appliance

Cisco C220 M3 Specifications

General

Maximum Processors	2
Memory Slots	24 DIMM slots
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Remote Management	Cisco Integrated Management Controller (CIMC)
Processor	Intel Xeon E5-2600 series
Memory	Up to 768 GB
Network Interfaces	2 x 1GbE ports
Expansion Slots	3 x PCIe 3.0 slots
Power Supply	650W hot-plug redundant
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Form Factor	1U rack server
