Chapter 1 Overview
Deployment Examples
1-14
Catalyst 2900 Series XL Modules Hardware Installation Guide
78-5912-03
Figure 1-11 Small- to Medium-Sized LAN Backbone
31670
Catalyst 2924M XL
Legacy
10BaseT Hub
FastHub
10/100 Hub
Gigabit Ethernet,
Fast EtherChannel
or 100BaseTX
Catalyst 1900 or
Catalyst 2900 XL
Switches
Workstations/Servers
