Page #16 background imageLoading...
Page #16 background image
Cisco Systems, Inc.
All contents are Copyright © 2002 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.
Page 16 of 19
Standards
IEEE 802.1x
IEEE 802.1w
IEEE 802.1s
IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports
IEEE 802.1D Spanning-Tree Protocol
IEEE 802.1p class-of-service (CoS) prioritization
IEEE 802.1Q VLAN
IEEE 802.3 10BASE-T specification
IEEE 802.3u 100BASE-TX specification
IEEE 802.3ab 1000BASE-T specification
IEEE 802.3z 1000BASE-X specification
•1000BASE-SX (SFP)
•1000BASE-LX (SFP)
RMON I and II standards
SNMPv1, SNMPv2c, SNMPv3
Y2K
Y2K compliant
Connectors and
Cabling
LRE ports: RJ-21 connector; one-pair Category 1, 2, or 3 unshielded twisted-pair (UTP)
cabling
•10BASE-T ports: RJ-45 connectors; two-pair Category 3, 4, or 5 unshielded twisted-pair
(UTP) cabling
•100BASE-TX ports: RJ-45 connectors; two-pair Category 5 UTP cabling
•1000BASE-T ports: RJ-45 connectors; two-pair Category 5 UTP cabling
•1000BASE-SX and -LX SFP-based ports: SC fiber connectors, single-mode or multimode
fiber
Management console port: 8-pin RJ-45 connector, RJ-45-to-RJ-45 rollover cable with
RJ-45-to-DB9 adapter for PC connections; for terminal connections, use RJ-45-to-DB25
female data-terminal-equipment (DTE) adapter (can be ordered separately from Cisco, part
number ACS-DSBUASYN=)
Power Connectors
Customers can provide power to a switch by using either the internal power supply or the
Cisco Redundant Power System (RPS) 300. The internal power supply connector is located in
the front of the switch and the RPS connector is located at the back of the switch.
Internal Power Supply Connector
The internal power supply is an auto-ranging unit.
The internal power supply supports input voltages between 100 and 240 VAC.
Use the supplied AC power cord to connect the AC power connector to an AC power outlet.
Cisco RPS Connector
The connector offers connection for an optional Cisco RPS 300 that uses AC input and
supplies DC output to the switch.
The connector offers a 300-watt redundant power system that can support six external
network devices and provides power to one failed device at a time.
The connector automatically senses when the internal power supply of a connected device
fails and provides power to the failed device, preventing loss of network traffic.
•Attach only the Cisco RPS 300 (model PWR300-AC-RPS-N1) to the
redundant-power-supply receptacle.
Indicators
•Per-port status LEDs: link integrity, disabled, activity, and speed (uplinks only) indications.
•System status LEDs: system and RPS indications.
Feature
Description

Other manuals for Cisco Catalyst 2950

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco Catalyst 2950 and is the answer not in the manual?

Cisco Catalyst 2950 Specifications

General IconGeneral
Forwarding Bandwidth8.8 Gbps
Switching Capacity13.6 Gbps
Forwarding Rate6.6 Mpps
Weight3.6 kg
RAM16 MB
Flash Memory8 MB
Operating Humidity10% to 85% non-condensing
Uplink Ports2 x 10/100/1000Base-T
Dimensions4.4 cm x 44.5 cm x 24.2 cm
Remote Management ProtocolSNMP, Telnet, HTTP
FeaturesQuality of Service (QoS), VLAN support
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicatorssystem
Operating Temperature0 to 45°C
Ports24 x 10/100 Ethernet ports
MAC Address Table Size8, 192 entries
Power SupplyInternal 100-240V AC, 50-60Hz
