Cisco Catalyst 3850 Configuration Guide

C O N T E N T S
Cisco Express Forwarding
1
Finding Feature Information 1
Information About CEF 1
Cisco Platform Support for CEF and dCEF 2
CEF Benefits 2
Media Supported by CEF 3
Main Components of CEF 4
FIB Overview 4
CEF FIB and Load Balancing 4
CEF Adjacency Tables Overview 4
Adjacency Discovery 5
Adjacency Types That Require Special Handling 5
Unresolved Adjacency 6
Central CEF Mode Operation 6
Distributed CEF Mode Operation 6
CEF Features Enabled by Default 7
CEF Distributed Tunnel Switching 8
Links for the CEF Features 8
How to Configure CEF 8
Configuration Examples for CEF 9
Additional References 9
Feature Information for Cisco Express Forwarding 10
IP Switching Cisco Express Forwarding Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3850 Switches)
iii

Cisco Catalyst 3850 Specifications

General

Stacking Bandwidth	480 Gbps
Max Stacking Units	9
Form Factor	Rack-mountable
RAM	4 GB
Flash Memory	4 GB
Operating System	Cisco IOS XE
Model	Catalyst 3850
Ports	24 or 48 Gigabit Ethernet ports
Uplink Interfaces	4 x 1GE, 2 x 10GE, or 4 x 10GE
Power Supply	Redundant power supplies
Dimensions	44.5 x 44.8 x 4.45 cm
Weight	7.6 kg
Features	IPv6
Power over Ethernet (PoE)	PoE, PoE+, UPOE (varies by model)
Operating Temperature	0 to 40°C
