1
Power supplies that are ordered are installed in the switch. If the second power supply is not ordered, a blank panel is installed.
Figure 2: Catalyst 6832-X-LE
Console port (RJ-45 Serial)632 10G SFP+ ports or 100 MB or 1G SFP
fiber-optic ports
1
Catalyst 6840-X Switch Series Hardware Installation Guide
4
Product Overview
Front Panel Components
