five on each side) either 10-32 or 12-24 clip or cage nuts over the rack post holes to accept the installation
screws.
Clip nuts or cage nuts are not included as part of the accessory kit that comes with the chassis. You
must obtain them yourself.
Note
Step 5
If you want to install one or both of the optional cable guide assemblies, position the cable guides so that the
cable guide mounting holes are aligned with L bracket holes as shown in figure below.
Figure 20: Installing the Cable Mount Guides
Cable guide1
Catalyst 6880-X Switch Hardware Installation Guide
26 OL-30827-02
Installing the Switch
Rack Mouting the Chassis
