Cisco Catalyst 9166 Series - Preinstallation Checks and Installation Guidelines

Figure 8: CW9166I - Client-Serving Normalized Radiation Pattern
(6-GHz Elevation)
Figure 7: CW9166I - Client-Serving Normalized Radiation Pattern
(6-GHz Azimuth)
Figure 10: CW9166I - XOR Normalized Radiation Pattern (5-GHz
Elevation)
Figure 9: CW9166I - XOR Normalized Radiation Pattern (5-GHz
Azimuth)
Cisco Catalyst 9166 Series Wi-Fi 6E Access Point Hardware Installation Guide
11
Hardware Features
CW9166I (Internal Antenna) Radiation Patterns
