Removing the Switching Module
Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. Statement
1034
Warning
Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into beams or view directly with
optical instruments. Statement 1051
Warning
Before you begin
You will need a blank module filler plate (C9400-S-BLANK) if the module slot is to remain empty.
Procedure
Step 1 Disconnect any network interface cables attached to the module ports.
Step 2 If the module is equipped with removable optical transceivers, immediately install dust plugs into the transceiver’s optical
bores. This prevents possible dust contamination, which can affect port performance.
Step 3 With a Phillips screwdriver, completely loosen the two captive screws located at each end of the module faceplate.
Step 4 Grasp the left and right ejector levers and simultaneously pivot the levers outward to eject the module from the backplane
connector.
24
