Powering the Access Point
The AP supports these power sources:
• DC power – 24–48 VDC
• Power-over-Ethernet (PoE)
The AP can be powered via the PoE input from an inline power injector or a suitably powered switch port.
Depending on the configuration and regulatory domain, the required power for full operation is 802.3bt or
UPOE.
For more information, see Power Sources.
Power Feature Matrix
The following table provides the AP power feature matrix.
Table 4: Catalyst IW9167EH Access Point Power Feature Matrix
SFPmGig
Eth
GNSSAux
Radio
dBm Per
Path
5 GHz / 6
GHz
Radio
dBm Per
Path
5 GHz
Radio
dBm Per
Path
2.4 GHz
Radio
Power
Input
Yesmax 5GYesYes174x4244x4244x424-48V
Yesmax 5GYesYes174x4244x4244x4802.3bt/
UPOE
Yes/1Gmax 1GYesYes172x2232x2232x2802.3at
Connecting to the DC Power Port Using Certified Cable Gland or Flex Conduit
Follow these steps to connect to the DC power port using certified Cable Gland or Flex Conduit (not supplied):
Procedure
Step 1 Remove the M25 plug. Separate the Gland Connector as per the manufacturers instructions and pass the DC cable through
it.
