Table 30: Console Port Signaling with a DB-9 Adapter

Console

Device

RJ-45-to-DB-9

Terminal Adapter

Switch Console

Port (DTE)

SignalDB-9 PinSignal

RxD2TxD

GND5GND

TxD3RxD

Table 31: Console Port Signaling with a DB-25 Adapter

Console

Device

RJ-45-to-DB-25

Terminal Adapter

Switch Console

Port (DTE)

SignalDB-25 PinSignal

RxD3TxD

GND7GND

TxD2RxD
