Figure 2: Front Panel of a Cisco Catalyst 9500 High Performance Switch (C9500-32C)
RFID532 40G/100G QSFP28 ports1
Console port (RJ-45 Serial)6Ethernet management port2
USB 3.0 host port7Reset button3
USB mini Type B console port4
Cisco Catalyst 9500 Series Switches Hardware Installation Guide
8
Product Overview
Front Panel
