Cisco Catalyst C9500-24Y4C User Manual

CONTENTS
Preface 1
CHAPTER 1
Document Conventions 1
Related Documentation 3
Obtaining Documentation and Submitting a Service Request 3
Product Overview 5
CHAPTER 2
Switch Models 6
Front Panel 7
SFP and QSFP Module Ports 10
Port Mapping for Cisco Catalyst 9500 Series Switches 11
Port Mapping for Cisco Catalyst 9500 Series High Performance Switches 14
RFID Tag 17
Console Ports 17
Management Port 18
USB Host Ports 18
Mode Button 18
Network Modules 18
Rear Panel 19
SATA SSD Module 21
Power Supply Slots 21
Fan Modules 22
Preparing for Installation 23
CHAPTER 3
Safety Warnings 23
Site Requirements 25
Cisco Catalyst 9500 Series Switches Hardware Installation Guide
ii
Contents

Cisco Catalyst C9500-24Y4C Specifications

General

Model	C9500-24Y4C
Category	Switch
Product Series	Catalyst 9500
Switching Capacity	1.92 Tbps
Forwarding Rate	1.44 Bpps
Rack Units	1RU
Operating System	Cisco IOS XE
RAM	16 GB
Flash Memory	16 GB
VLANs Supported	4096
Operating Temperature	32°F to 104°F (0°C to 40°C)
Ports	24 x 25 Gigabit Ethernet ports and 4 x 100 Gigabit Ethernet QSFP28 ports
Redundancy	Power supply
Stacking	Yes
Jumbo Frame Support	9198 bytes
MAC Address Table Size	128, 000 entries
Operating Humidity	5% to 90% non-condensing
Power Supply	Dual hot-swappable power supplies
Weight	16.33 lbs (7.41 kg)
