Fan LED
Table 27: Fan LED Indicator
DescriptionColor/State
The fan is not receiving power; the fans have stopped.Off
All fans are operating normally.Green
One or more fans have encountered tachometer faults.Amber
One or more fans' tachometer faults have exceeded the maximum limit.Red
Ethernet Management Port LED
The following table describes the colors and the descriptions of the LEDs for link activity and link status of
the Ethernet management port.
Table 28: Ethernet Management Port Link Activity LED
DescriptionColor
Link is up.Blinking green
Link is down.Off
Table 29: Ethernet Management Port Link Status LED
DescriptionColor
Link is up.Solid green
Link is down.Off
Cisco Catalyst 9500 Series Switches Hardware Installation Guide
111
Understanding the LEDs
Fan LED
