Figure 3: Front Panel of a 48-Port Cisco Catalyst 9500 High Performance Switch (C9500-48Y4C)
USB mini Type B console port548 1G/10G/25G SFP28 ports1
RFID6Uplink ports2
Console port (RJ-45 Serial)7Ethernet management port3
USB 3.0 host port8Reset button4
Cisco Catalyst 9500 Series Switches Hardware Installation Guide
9
Product Overview
Front Panel
