Figure 16: Rear Panel of a Cisco Catalyst 9500 High Performance Switch (C9500-32C)
Fan 37Power supply modules1
Fan 28Fan modules2
Fan 19Grounding pad3
Fan 010SATA SSD module4
PSU 011PSU 15
--Fan 46
Figure 17: Rear Panel of a Cisco Catalyst 9500 High Performance Switch (C9500-32QC, C9500-48Y4C, and C9500-24Y4C)
PSU 15Power supply modules1
Fan 16Grounding pad2
Fan 07Fan modules3
PSU 08SATA SSD module4
Cisco Catalyst 9500 Series Switches Hardware Installation Guide
20
Product Overview
Rear Panel
