Fan Modules
The switch supports field-replaceable, variable-speed modular fans with default front-to-back airflow. These
fan units support Online Insertion and Removal (OIR) for up to 120 seconds. The fan unit is responsible for
cooling the entire chassis and interfacing with environmental monitors to trigger alarms when conditions
exceed thresholds.
The following table describes the fan modules supported on different switch models.
Table 11: Fan Modules
Switches SupportedFan ModulesPart Number
Cisco Catalyst 9500 Series
switches:
C9500-12Q
C9500-24Q
C9500-40X
C9500-16X
Type 4 front to back cooling fanFAN-T4-R=
Cisco Catalyst 9500 Series High
Performance switches:
C9500-32QC
C9500-48Y4C
C9500-24Y4C
Hot-swappable fan tray unit with
dual stacked fans.
C9K-T1-FANTRAY=
Cisco Catalyst 9500 Series High
Performance switch:
C9500-32C
Type 4 front to back cooling fanC9K-T2-FANTRAY=
For more information, see Fan Module Overview , on page 80.
Cisco Catalyst 9500 Series Switches Hardware Installation Guide
22
Product Overview
Fan Modules
