For SMF connections, use one of the LCs listed in Table A-3 or Table A-4. For
MMF connections, use one of the LCs listed in Table A-5. Use the Cisco part
numbers to order the patch cables that you need, or order patch cables from your
vendor.
Table A-3 LC-to-SC Single-Mode Fiber Patch Cables (SFP-to-GBIC Connections)
Type Cisco Part Number
2-meter, LC-to-SC single-mode fiber patch cable CAB-CP-LCSC-2M
8-inch, SC-to-LC single-mode fiber patch cable CAB-CP-SCLC-8IN
10-foot, LC-to-SC single-mode fiber patch cable CAB-SMF-SC-10
100-foot, LC-to-SC single-mode fiber patch cable CAB-SMF-SC-100
25-foot, LC-to-SC single-mode fiber patch cable CAB-SMF-SC-25
50-foot, LC-to-SC single-mode fiber patch cable CAB-SMF-SC-50
75-foot, LC-to-SC single-mode fiber patch cable CAB-SMF-SC-75
Table A-4 LC-to-LC Single-Mode Fiber Patch Cables (SFP-to-SFP Connections)
Type Cisco Part Number
2-meter, LC-to-LC single-mode fiber patch cable 15454-LC-LC-2=
4-meter, LC-to-LC single-mode fiber patch cable 15216-LC-LC-5=
6-meter, LC-to-LC single-mode fiber patch cable 15216-LC-LC-10=
8-meter, LC-to-LC single-mode fiber patch cable 15216-LC-LC-20=
Table A-5 SX LC and SX LC-to-SC Multimode Fiber Patch Cables (SFP-to-SFP Connections)
Type Cisco Part Number
10-meter, SX LC multimode fiber patch cable CSS5-CABSX-LC=
10-meter, SX LC-to-SC multimode fiber patch cable CSS5-CABSX-LCSC=
