LED Behaviors
The following table lists the LED indicators and their behavior. The LEDs provide a visual indication of the
status and the currently selected services.
LED Indicators:
FunctionColorLED
Enable LEDGreen, YellowEN
Pluggable enable LED
Off: System power is off
Yellow: Module power is not functioning correctly
Green: Module power is on
SIM0 LED/ActivityGreen, YellowSIM0
SIM0 LED status and WWAN activity
Off: SIM0 is not installed
Yellow: SIM0 is installed, but not active
Green: SIM0 installed and active
Green Flash: LTE data activity
SIM1 LED/ActivityGreen, YellowSIM1
SIM1 LED status and WWAN activity
Off: SIM1 is not installed
Yellow: SIM1 is installed, but not active
Green: SIM1 installed and active
Green Flash: LTE data activity
GPS LEDGreen, YellowGPS
Off: GPS not configured
Yellow: Software defined
Green: GPS configured
Green Flash: GPS acquiring (flashing done by SW)
Service Indication LEDGreen, Yellow, BlueService
Yellow: 3G
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
51
5G Sub-6 GHz Pluggable Interface Module
LED Behaviors
