RXTXTechnologyAntenna
Port
3G
WCDMA
ANT 3
B1, B2, B3, B4, B7, B25, B30, B32, B34, B38,
B39, B40, B41, B42, B43, B46, B48, B66
4G LTE
n1, n2, n3, n7, n25, n38, n40, n41, n48, n66, n77,
n78, n79
5G NR FR1
Port Mappings for 5G-ANTM-0-4-B on the P-5GS6-GL PIM
The following table lists the port mappings using the 5G-ANTM-O-4-B antenna as an example, mapping to
the ports on the P-5GS6-GL pluggable module.
P-5GS6-GL5G-ANTM-O-4-B
ANT 0MAIN 0 (LTE1)
ANT 1MAIN 1 (LTE3)
ANT 2DIV 0 (LTE2)
ANT 3DIV 1 (LTE4)
GPSGNSS
The following link contains the antenna specifications and installation instructions for 5G NR
(5G-ANTM-O-4-B):
https://www.cisco.com/c/en/us/td/docs/routers/connectedgrid/antennas/installing-combined/
b-cisco-industrial-routers-and-industrial-wireless-access-points-antenna-guide/m-5g-antm-04b.html#Cisco_
Generic_Topic.dita_e780a6fe-fa46-4a00-bd9d-1c6a98b7bcb9
Thermal Mitigation
The following tables provide a description of thermal mitigation levels and throughput performance across
all IoT industrial routers.
This applies to both the 4G LTE and 5G NR FR1 operation of the P-5GS6-GL.
Table 9: Thermal Mitigation Levels
DescriptionLevel
Normal mode, no thermal throttling.Level 0
Uplink throttling, via reduced UL TX duty cycle.Level 1
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
53
5G Sub-6 GHz Pluggable Interface Module
Thermal Mitigation
