Cisco Catalyst IR1800 Rugged Series - WIM Thermal Mitigation

2.4 GHz Radio5 GHz Radio
RX sensitivity
(dBm)
Total TX power
(dBm)
RX sensitivity
(dBm)
Total TX power
(dBm)
Number of Active
Antennas
Spatial Streams
——-571621MCS11
——-852022MCS0
——-541622MCS11
Thermal Mitigation
The following table provides a description of thermal mitigation levels and throughput performance.
This applies to the IR1835 with dual P-LTEAP18-GL pluggable modules and the WP-WIFI6 pluggable
module.
Table 24: Thermal Mitigation Table - IR1835
Throughput PerformanceAirflow (LFM)Maximum Ambient
Temperature (C/F)
Hardware
Throttled, 1x1 SISO060°/140°IR1835 plus WP-WIFI6
Dual P-5GS6-GL
Throttled, 1x1 SISO4065°/149°
Throttled, 1x1 SISO4070°/158°
Normal, 2x2 MIMO20070°/158°
Under normal conditions both 2.4 and 5 GHz radios of the WP-WIFI6 pluggable operate in 2x2 MIMO mode,
with antenna ports A and B active. Upon exceeding the ambient temperature and airflow levels indicated in
the thermal mitigation table, both 2.4 and 5 GHz radios may throttle to 1x1 SISO. In 1x1 SISO mode only
antenna port A is active, and each radio is restricted to single spatial stream data rates.
