Figure 25: Module Placement
Screws1
Screw holes2
Step 3 After the module is properly inserted, tighten the module plate to the panel with the two screws. The screws
should be torqued to 2-3 in-lb (0.2-0.3 Newton meter).
Step 4 The installation is now complete.
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
67
SSD Module
Installing an SSD Module
