Cisco cBR Series - Page 9

Figure 6: Removing the Front Power Entry Bezel from the Chassis
Front power entry bezel2Screw1
Step 2 Loosen and remove the four #6-32 Torx-head screws on the Power Cassette Module using a T10 Torx screwdriver.
Step 3 Hold the side flanges on the Power Cassette Module with both your hands. Pull and slide the module out of the chassis
applying even pressure to both your hands.
9
