Figure 49: Routing the RJ-45 Cables Connected to the Supervisor PIC
—
Option 3
Cable ties3Strap-down clips1
Supervisor PIC cable management bracket4RJ-45 cable bundle2
Step 3
Repeat Step 1, on page 54 and Step 2, on page 57 for the cables connected to the each Supervisor PIC.
Using the USB Port on the Supervisor Card
Before You Begin
•
Install the Supervisor PIC.
•
Install the Supervisor Card.
Cisco Converged Broadband Routers Hardware Installation Guide
60
Installing the Supervisor in the Cisco cBR Chassis
Using the USB Port on the Supervisor Card
