Restrictions
The USB ports on the Supervisor Card are used for temporary connections. For all permanent connections,
you must use the ports on the Supervisor PIC.
Required Tools and Equipment
•
Memory stick or flash drive
Step 1
Open the tethered I/O door on the Supervisor Card by pulling on the left edge of the door until the door is released from
the spring-loaded ejector.
Figure 50: Opening the Tethered I/O Door on the Supervisor Card
—
Tethered I/O door1
Step 2
Connect the memory stick or flash drive to the USB port on the Supervisor Card.
Figure 51: Connecting the USB Drive to the USB Port
Cisco Converged Broadband Routers Hardware Installation Guide
61
Installing the Supervisor in the Cisco cBR Chassis
Using the USB Port on the Supervisor Card
