Broadband Scalability and Performance
PPP Sessions and L2TP Tunnel Scaling
2
Cisco ASR 1000 Series Aggregation Services Routers Software Configuration Guide
PPP Sessions and L2TP Tunnel Scaling
The ASR 1000 Series Routers are deployed in a variety of broadband deployment models for terminating
Point-to-Point Protocol (PPP) Sessions and initiating or terminating Layer 2 Tunneling Protocol (L2TP)
tunnels. The maximum number of PPP sessions and L2TP tunnels is dependent on the hardware
combination. Table 18 lists the hardware combinat
ions and the maximum number of PPP sessions and
L2TP tunnels that are supported
in Cisco IOS XE Release 3.3. For information about the restrictions for
PPP sessions and L2TP tunnel scaling, see the “Restrictions for PPP Sessions and L2TP Tunnel Scaling”
section on page 2.
Table 19 l
ists the virtual circuit limits for ASR 1000 ATM SPAs, effective from Cisco IOS XE
Release 3.5.
Restrictions for PPP Sessions and L2TP Tunnel Scaling
This section lists the restrictions for the PPP sessions and L2TP tunnel scalability.
• To achieve maximum scaling for the 1001, 1002, and 1004 chassis, we recommend software
redundancy be disabled for broadband applications, and only hardware redundancy be configured.
• Restrictions on 48000 session scaling with RP2 and ESP-40G include:
Ta b l e 18 Maximum Number of PPP Sessions and L2TP Tunnels Supported on ASR 1000
Hardware
Chassis RP ESP PPP Session L2TP Tunnel
1001 Integrated ESP-2.5G or
ES
P-5G
8000 4000
1002 Integrated
RP1
ESP-5G 12000 6000
1004, 1006 RP1 ESP-10G or
ES
P-20G
24000 12000
1004, 1006 RP2 ESP-20G 32000 16000
1004, 1006, 1013 RP2 ESP-40G 32000
1
, 48000, or 64000
1. 32000 session scaling with RP2 and ESP-40G is fully supported without any additional restrictions. For restrictions on 48000
and 64000 see the
“Restrictions for PPP Sessions and L2TP Tunnel Scaling” section on page 2.
64000
Ta b l e 19 ASR 1000 ATM Virtual Circuit (VC) Limits
ASR1000-SIP10 ASR1000-SIP40
SPA/SIP Number of VCs SPA/SIP Number of VCs
SPA-1XOC12-ATM-V2 4000 VCs per Port,
40
00 VCs per SPA
SPA-1XOC12-ATM-V2 4000 VCs per Port,
4000 VCs per SPA
SPA-1XOC3-ATM-V2 4000 VCs per Port,
40
00 VCs per SPA
SPA-1XOC3-ATM-V2 4000 VCs per Port,
4000 VCs per SPA
SPA-3XOC3-ATM-V2 3000 VCs per Port,
90
00 VCs per SPA
SPA-3XOC3-ATM-V2 4000 VCs per Port,
12000 VCs per SPA
ASR1000-SIP10 24000 VCs per SIP ASR1000-SIP40 32000 VCs per SIP
