Cisco DX70 Installation Guide

4
Start the System
1. Push the power button to start up the DX70. The power button’s LED lights up when
the device starts up.
2. Follow the on-screen instructions to set up the system.
For more information on how to set up the system, see the Administrator Guide at
http://www.cisco.com/go/dx-docs
Connect to Computer and Monitor
Connect your computer to the DX70 to enable content sharing and to use it as a monitor
for your computer.
Connect an HDMI cable between the DX70
3
and your computer. You may need an
adapter for the HDMI cable, depending on the connectors available on your computer.
3
The DX70 can be connected to an external monitor via the HDMI out port.

Cisco DX70 Specifications

General

Connectivity	Ethernet, Wi-Fi
Video Standards	H.264
Operating System	Android-based
Power over Ethernet (PoE)	Yes
Microphone	Integrated microphone
Speaker	Integrated
Audio Standards	G.711, G.722
Mounting Options	Wall mount
