Cisco DX70 Installation Guide

5
Front and Side Panels
Turn the privacy shutter to open and close the camera.
Use the source button to show and hide your computer screen when a computer is
connected to the DX70.
Adjust Camera and Stand
Power button
Speaker
Microphone
Camera privacy shutter
Microphone mute
Volume
USB charging port
Micro-SD card slot
Mini jack 3.5 mm output
You can tilt the camera to adjust the camera angle and to activate the document camera
feature.
Adjust the foot stand to take advantage of the extended tilt of the touch screen.
Source button

Cisco DX70 Specifications

General

Connectivity	Ethernet, Wi-Fi
Video Standards	H.264
Operating System	Android-based
Power over Ethernet (PoE)	Yes
Microphone	Integrated microphone
Speaker	Integrated
Audio Standards	G.711, G.722
Mounting Options	Wall mount
