The following figure shows the default network deployment for the threat defense using the device manager
with the default configuration.
Figure 25: Suggested Network Deployment
For 6.7 and earlier, the inside IP address is 192.168.1.1.
For 6.5 and earlier, the Management 1/1 default IP address is 192.168.45.45.
Note
Default Configuration
The configuration for the firewall after initial setup includes the following:
• inside—IP address (7.0 and later) 192.168.95.1; (pre-7.0) 192.168.1.1.
• (6.5 and later) Hardware switch—Ethernet 1/2 through 1/8 belong to VLAN 1
• (6.4) Software switch (Integrated Routing and Bridging)—Ethernet 1/2 through 1/8 belong to bridge
group interface (BVI) 1
• outside—Ethernet 1/1, IP address from IPv4 DHCP and IPv6 autoconfiguration
Cisco Firepower 1010 Getting Started Guide
92
Threat Defense Deployment with the Device Manager
Default Configuration
