Gigabit Interface Converter (GBIC) Module and Small Form-Factor Pluggable (SFP) GBIC Module Installation Information and Specifications
OL-5067-08
CWDM GBIC Module and SFP Module Description and Information
Parameters are specified over temperature and at end of life unless otherwise noted.
When shorter distances of single-mode fiber are used, it may be necessary to insert an in-line optical
attenuator in the link to avoid overloading the receiver.
Receiver optical
input power
(BER <10-12 with
PRBS 2-7-1)
P
in
–29.0 –33.0 –7.0 dB @ 1.25 Gbps, 140°F (60°C) case
temperature
Optical input
wavelength
λ
in
1450 – 1620.0 nm –
Transmitter
extinction ratio
OMI 9 – – dB –
Dispersion penalty at
100 km
– – – 3.0 dB @ 1.25 Gbps
Table 10 CWDM GBIC Module Optical Parameters (continued)
Parameter Symbol Minimum Typical Maximum Units Notes/Conditions
Table 11 CWDM SFP Module Options
Product Number Description Color
CWDM-SFP-1470= Cisco 1000BASE-CWDM SFP 1470 nm Gray
CWDM-SFP-1490= Cisco 1000BASE-CWDM SFP 1490 nm Violet
CWDM-SFP-1510= Cisco 1000BASE-CWDM SFP 1510 nm Blue
CWDM-SFP-1530= Cisco 1000BASE-CWDM SFP 1530 nm Green
CWDM-SFP-1550= Cisco 1000BASE-CWDM SFP 1550 nm Yellow
CWDM-SFP-1570= Cisco 1000BASE-CWDM SFP 1570 nm Orange
CWDM-SFP-1590= Cisco 1000BASE-CWDM SFP 1590 nm Red
CWDM-SFP-1610= Cisco 1000BASE-CWDM SFP 1610 nm Brown
Table 12 CWDM SFP Module Electrical Power Interface Information
Parameter Symbol Minimum Typical Maximum Units
Supply current I
s
– 220 300 mA
Surge current I
Surge
––+30 mA
Input voltage V
max
3.1 3.3 3.6 V
