22
Connecting to an SD
TV with a SCAR
T Connector
Cables Used in this Con
guration
•
MiniDin to SCART A
dapter Cable
W
ARNING:
Electric shock hazard! Unplug all electronic de
vices before connecting or
disconnecting any device cables to the set
-top.
Back of Set-T
op
S/PDIF
SCART
HDMI
ETHERNET
Reset
12V DC
CABLE/
ANTENNA
SCART VIDEO IN
Back of
TV
CABLE/
ANTENNA
SCART VIDEO IN
T16450
21
23
