Cisco ISB7105 - Connecting to an SDTV with an RCA-Type Connector; RCA-Type Cable Configuration

20
Connecting to an SDTV with an RCA-Type Connector
Cables Used in this Con guration
• 1 RCA-type Video Cable
• 1 Audio Left/Right Cable
WARNING: Electric shock hazard! Unplug all electronic devices before
connecting or disconnecting any device cables to the receiver.
Receiver
T15882
NETWORK
L R
Pr Pb Y VIDEO
OUT
AUDIO
OUT
OPTICAL POWER
HDMI
®
CABLE OUT/
ANT OUT
RL
AUDIO
IN
VIDEO
IN
RL
AUDIO
OUT
VIDEO
OUT
Y
PB
PR
CABLE IN/
ANT IN
Back of
SDTV
