1-3
Installation Guide for Cisco Unified Videoconferencing Manager Release 5.5
OL-14925-01
Chapter 1 Installing Cisco Unified Videoconferencing Manager
Pre-installation
Port Requirements
Table 1-1 shows the required ports for Cisco Unified Videoconferencing Manager. Make sure all
required ports are available.
Table 1-1 Required Ports
Protocol Ports Type Direction Purpose Destination
Cisco Unified Videoconferencing Manager Server Ports
HTTP 80 TCP In from Web Web UI access and Web Service
access
Cisco Unified
Videoconferencing Manager
XML 3336 TCP In from Desktop Cisco Unified Videoconferencing
Manager’s version of MCU Call
Control XML API
Cisco Unified
Videoconferencing Manager
Internal
gatekeeper
HTTP
8011 TCP In from Web Web UI access. Disabled by
default.
Cisco Unified
Videoconferencing Manager
Database
connection
3306 TCP Local database
connection
If the internal database is installed,
the application communicates with
the database using port 3306.
Cisco Unified
Videoconferencing Manager
SNMP 161 UDP In from Resource
Manager and Network
Manager
Configuration/
Status
Cisco Unified
Videoconferencing Manager
FTP 21 TCP In from Network
Manager
Log retrieval Cisco Unified
Videoconferencing Manager
XML 3271 TCP Local connection Resource Manager connects to the
XML API interface of the internal
gatekeeper
Cisco Unified
Videoconferencing Manager
MCU Ports
HTTP 80 TCP In from Web Web UI access MCU
XML 3336 TCP In from Resource
Manager
MCU Call Control XML API MCU
XML 3337 TCP In from another MCU or
Desktop
MCU Cascade XML API MCU
SNMP 161 UDP In from Resource
Manager and Network
Manager
Configuration/Status MCU
Telnet 23 TCP In from Network
Manager
Log retrieval and advanced
commands
MCU
Gateway Ports
HTTP 80 TCP In from Web Web UI access gateway
SNMP 161 UDP In from Resource
Manager and Network
Manager
Configuration/Status gateway
Telnet 23 TCP In from Network
Manager
Log retrieval and advanced
commands
gateway
