The Z1 front panel
Ports and Status Indicators
The Z1 uses a single LED to inform the user of the device's status.
LED Status Meaning
Flashing white Operation in progress
Solid white Power is applied, Fully operational
The Z1 back panel
Additional functions on the back panel are described below, from left to right.
Reset button
Insert a paper clip if a reset is required.
• A brief, momentary press: To delete a downloaded
configuration and reboot.
• Press and hold for more than 10 sec: To force the
unit into a full factory reset.
2
