Cisco MX200 Series - Adjusting Camera with Self-View

8
D1458217 User Guide Cisco TelePresence
Prole Series, Codec C-series, Quick Set C20
SX20 Quick Set, MX200, MX300
Produced: November 2013 for TC7.0
All contents © 2010–2013
Cisco Systems, Inc. All rights reserved.
Before the meeting starts we
recommend that you check the self-
view of your video system.
The self-view shows what others
see from your video system. You will
normally use it to conrm that they
see what you want them to see.
The self-view appears as a PiP
(Picture-in-Picture).
The position of self-view PiP can be
changed if you wish—see “Moving
the self-view PiP” on page 29 for
details on this.
Getting up and going
Using self-view to adjust the camera
About self-view
Tap Self-view, as outlined.
Watch the
screen of your
video system
and use the
camera controls to adjust the
camera’s pan tilt and zoom, if
needed.
To exit this
menu, putting
changes into eect,
tap anywhere
outside the active
menu.
Pan
Tilt
Zoom
