In-Room Control on Touch10
for Cisco TelePresence
MX200 G2, MX300 G2,
MX700, MX800,
SX10, SX20, SX80
Collaboration Endpoint
software version CE8.2
D15358.02 - JULY 2016
www.cisco.com
© 2016 Cisco Systems, Inc.
All rights reserved.
4
Introduction
With In-Room Control you can add custom elements to our Touch 10
user interface. Such user interface extensions may be controls for
lights or blinds, or other peripherals controlled by external control
systems.
Since both the Cisco video system and the other peripherals now are
controlled from the Touch 10 user interface, you will get a consistent
user experience throughout the meeting room.
The version of the in-room control feature described in this
document, is available for the SX Series and MX Series video
systems running Collaboration Endpoint Software, version CE8.2 or
later.
Definition of terms
Video system. Video system or codec in the Cisco TelePresence
MXSeries or SXSeries running Collaboration Endpoint Software,
version CE8.2 or later. Sometimes referred to as video device.
Control system. Third-party control system with hardware drivers for
peripherals, for example Crestron, AMX, Apple HomeKit, or Android.
Tou ch 10. Out touch-based control device for the MXSeries and
SXSeries video systems. Full product name: Cisco TelePresence
Touch 10. Also known as Touch 10 controller, or Touch 10 user
interface.
In-room control panel. Panel with controls for third-party peripherals
in the room. The panel opens when you tap the corresponding
in-room control icon in the status bar on Touch 10. See the
Create a user interface chapter for more on this.
In-room control editor. Our easy to use drag-and-drop editor for
making in-room control panels.
xAPI. The bidirectional API of the video system. The xAPI allows
third-party applications to interface with and interact with the video
system, and vice versa.
Widget. User interface element, for example buttons, sliders, and
text fields, that you can use to build an in-room control panel for
Touch 10.
