MX450 Front Panel
Ports and Status Indicators
The MX450 uses LEDs to inform the user of the device's status. When the device powers on, all the Internet LEDs flash twice. Additional functions are described
below, from left to right.
Item Function LED Status Meaning
1 Power Solid orange Power is applied
Rainbow colors
Unit is attempting to contact the
Cloud
Flashing white Operation is in progress
Solid white Fully operational
2 USB connectivity Off During boot or USB link
Solid orange Initial link
Flashing orange Internet connectivity not complete
Green USB connection detected
3 HA status Off No HA available
Orange Initial link
Flashing orange High availability not complete
Green HA available
Reset button
Insert a paper clip if a reset is required.
A brief, momentary press: To delete a downloaded configuration and reboot.
Press and hold for more than 10 seconds: To force the unit into a full factory reset.
MX450 Back Panel
2
