Cisco NCS 2000 series

Figure 7: Mounting the MF-6RU Unit for a 19-inch ANSI Equipment Rack
Washer2Screw1
Figure 8: Mounting the MF10-6RU Unit for a 19-inch ANSI Equipment Rack
Washer2Screw1
Step 3 Establish grounding for the MF-6RU or MF10-6RU unit:
Installing the Cisco NCS 2000 Series Passive Optical Modules
11
Installing the Cisco NCS 2000 Series Passive Optical Modules
MPO Fan-out Unit
