Replacing Memory on a Cisco Nexus 7000 Series I/O Module
78-100406-01
Replacing a DIMM on an I/O Module
Figure 1 Metal Cover on the Back of the I/O Module
Step 10
On the memory slot on the front of the I/O module, rotate both spring clips out.
Step 11 Holding the edges of the DIMM with your fingers, slide it out of its memory slot
and place it in an antistatic bag. See Figure 2.
1 Metal Cover
