Switch and Module Weights and Quantities
QuantityWeight per UnitComponent
114.12 lb (6.4 kg)Cisco Nexus 92348GC-X Chassis (N9K-C93248GC-X)
4—
0.26 lb (0.12 kg)
Fan Module
– Port-side exhaust (blue) (NXA-FAN-30CFM-F)
– Port-side intake (burgundy) (NXA-FAN-30CFM-B)
2 (1 for
operations
and 1 for
redundancy)
—
2.42 lb (1.1 kg)
2.42 lb (1.1 kg)
2.2 lb (1 kg)
2.2 lb (1 kg)
2.42 lb (1.1 kg)
2.42 lb (1.1 kg)
Power Supplies
– 400-W AC port-side exhaust (blue) (N2200-PAC-400W)
– 400-W AC port-side intake (burgundy) (N2200-PAC-400W-B)
– 350-W DC port-side intake airflow (N3K-PDC-350W-B)
– 400-W DC port-side exhaust airflow (blue coloring) (N2200-PDC-400W)
– 500-W PHV port-side exhaust airflow (blue coloring) (NXA-PHV-500W)
– 500-W PHV port-side intake airflow (red coloring) (NXA-PHV-500W-B)
Transceiver and Cable Specifications
To determine which transceivers, adapters, and cables are supported by this switch, see https://www.cisco.com/
c/en/us/support/interfaces-modules/transceiver-modules/products-device-support-tables-list.html.
To see the transceiver specifications and installation information, see https://www.cisco.com/c/en/us/support/
interfaces-modules/transceiver-modules/products-device-support-tables-list.html.
Switch Power Input Requirements
The following table lists the typical amount of power that the switch consumes. It also lists the maximum
amount of power that you must provision for the switch and power supply for peak conditions.
Some power supplies have capabilities that are greater than the maximum power requirements for a switch.
To determine the power consumption characteristics for the switch, use the typical and maximum requirements
that are listed in the following table.
Note
Heat Dissipation
Requirement
Maximum Power
Consumption (AC or DC)
Typical Power
Consumption (AC or DC)
Switch
1194.249 BTUs per hour350 W135 WCisco Nexus 92348GC-X
