Chapter 2 Install Cards and Fiber-Optic Cable
NTP- A17 Install the Electrical Cards
Stop. You have completed this procedure.
NTP-A17 Install the Electrical Cards
Warning
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself.
Statement 94
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the wristband
cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
Caution Do not install low-density DS-1 cards in the same side of the shelf as DS3/EC1-48 cards.
Caution Do not install a DS3/EC1-48 card in Slots 1 or 2 if you have installed an MXP_2.5G_10G card in Slot 3.
Likewise, do not install a DS3/EC1-48 in Slots 16 or 17 if you have installed an MXP_2.5G_10G card
in Slot 15. If you do, the cards will interact and cause DS-3 bit errors.
Note If protective clips are installed on the backplane connectors of the cards, remove the clips before
installing the cards.
Note Install higher-capacity cards first; for example, install a DS-3 card before installing a DS-1 card. Let
each card boot completely before installing the next card.
Note If you are installing OC-N, transponder (TXP), or muxponder (MXP) cards, Cisco recommends that you
install these before you install electrical cards, as applicable.
Step 1 If you installed XC or XCVT cards, review Table 2-1 on page 2-3 to determine card/slot compatibility.
If you installed XC10G or XC-VXC-10G cards, review Table 2-2 on page 2-5 to determine card/slot
compatibility.
Purpose This procedure describes how to install electrical cards (DS-1, DS-3,
DS3XM, and EC-1).
Tools/Equipment Electrical cards
Prerequisite Procedures NTP-A15 Install the Common Control Cards, page 2-2
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
