Cisco Router Cisco 3600 Installation Guide

5-26
Cisco 3600 Series Hardware Installation Guide
OL-2056-02
Chapter 5 Installing Memory in the Router
Replacing the ROM
Figure 5-20 ROM Location on the Cisco 3640 Mainboard
Figure 5-21 ROM Location on the Cisco 3660 Mainboard
Step 4 If you have a Cisco 3620 or Cisco 3640 router, gently remove the old ROM with a ROM extraction tool
or a small flat-blade screwdriver, and set it aside.
If you have a Cisco 3660 router, gently remove the old ROM with a 32-pin PLCC extractor, and set it
aside. (See Figure 5-22.)
H7083
ROM
ROM
17341
