Cisco SE2800 User Manual

25
Note When source A and source B are wired with common negative terminals, as in Figure 22, discharging does not occur
and there is no restriction requiring that source A and source B voltages be equal.
Figure 23 Connecting Source A and Source B with Common Positive Terminals
In Figure 24, source A and source B are wired with opposite polarity grounds. Do not use this configuration.
Caution Do not use the DC input configuration shown in Figure 24.
Figure 24 Source A and Source B Wired with Opposite-Polarity Grounds
A-
A+
B+
B-
Va
Vb
+
+
127040
A-
A+
B+
B-
Va
Vb
+
+
A-
Va voltage = Vb voltage (within 0.25 V)
Va voltage = Vb voltage (greater than 0.25 V)
A+
B+
B-
Va
Vb
+
+
A-
127041
A+
B+
B-
Va
Vb
+
+
A-
A+
B+
B-
Va
Vb
+
+
