1-6
Cisco Content Delivery Engine 100/200/300/400 Hardware Installation Guide
OL-13478-03
Chapter 1 Overview of the Content Delivery Engines
Hardware Features
Control Buttons
Figure 1-9 shows the CDE100 front panel, and describes the front panel control buttons.
Figure 1-9 CDE100 Front Panel Control Buttons
Note You may need to use a pen or the end of a straightened paper clip to press the Power and Reset buttons.
The Reset button does not restore the device to the factory default software settings.
CDE300 3 2 dual-core Intel
Xeon processors
Up to16 GB Up to 16 SCSI hard drives 12 full-duplex
GE interfaces
2
—
CDE400 4 2 dual-core Intel
Xeon processors
Up to 16 GB Up to 24 SATA hard
drives
3
— 8
4
1. Provides management communication with the CDSM.
2. Normally configured with 12 full-duplex Gigabit Ethernet (GE) interfaces, each used to deliver up to 250 simultaneous streams and to receive new content
from the CDE200 or CDE400.
3. Each drive contains 300 or 400 GB of storage. Each CDE400 can therefore contain up to 2400 hours of standard definition content (3840 hours on a
400-GB drive), including storage of information to support trick play.
4. Six Ethernet interfaces for content movement, an interface for ingest, and an interface for system management.
Table 1-1 CDE Hardware Features (continued)
CDE
Rack Unit
(RU) Processor Memory Drives GE Ports
Ethernet
Interface
1 Power Powers up the device.
2 Reset Resets the device and runs the power-on self-test (POST).
3 CD eject Opens the CD drive tray.
2
11766
3
1
2
