Port Management
Green Ethernet
198 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
10
• Port LEDs—Select to enable the port LEDs. When these are disabled, they do not
display link status, activity, etc.
• 802.3 Energy Efficient Ethernet (EEE)— Globally enable or disable EEE mode.
STEP 3 Click Reset Energy Saving Counter—To reset the Cumulative Energy Saved information.
STEP 4 Click Apply. The Green Ethernet Properties are written to the Running Configuration file.
Port Settings
The Port Settings page displays the current Green Ethernet and EEE modes per port, and
enables configuring Green Ethernet on a port using the Edit Port Setting page. For the Green
Ethernet modes to operate on a port, the corresponding modes must be activated globally in
the Properties page.
EEE settings are only displayed for devices that have GE ports. EEE works only when ports
are set to Auto negotiation. The exception is that EEE is still functional even when Auto
Negotiation is disabled, but the port is at 1GB or higher.
The Short reach and Energy Detect features are always enabled on XG devices and cannot be
disabled. On devices with FE or GE ports these features can be enabled or disabled.
To define per port Green Ethernet settings:
STEP 1 Click Port Management > Green Ethernet > Port Settings.
The Port Settings page displays the following:
• Global Parameter Status—Displays following:
- Energy Detect Mode—Whether this mode is enabled or not.
- Short Reach Mode—Whether this mode is enabled.
- 802.3 Energy Efficient Ethernet (EEE) Mode—Whether this mode is enabled.
For each port the following fields are described:
NOTE Some fields may not be displayed on some SKUs.
• Port—The port number.
• Energy Detect—State of the port regarding the Energy Detect feature:
- Administrative—Displays whether Energy Detect is enabled.
