VLAN Management
Voice VLAN
260 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
12
This may take several seconds. After several seconds have passed, refresh the page by exiting
it and reentering it.
To delete all the OUIs, select the top checkbox. All the OUIs are selected and can be deleted
by clicking Delete. If you then click Restore Default OUIs, the system recovers the known
OUIs.
STEP 4 To add a new OUI, click Add.
STEP 5 Enter the values for the following fields:
• Telephony OUI—Enter a new OUI.
• Description—Enter an OUI name.
STEP 6 Click Apply. The OUI is added to the Telephony OUI Table.
Telephone OUI Interface
The QoS attributes can be assigned per port to the voice packets in one of the following
modes:
• All—Quality of Service (QoS) values configured to the Voice VLAN are applied to all
of the incoming frames that are received on the interface and are classified to the Voice
VLAN.
• Telephony Source MAC Address (SRC)—The QoS values configured for the Voice
VLAN are applied to any incoming frame that is classified to the Voice VLAN and
contains an OUI in the source MAC address that matches a configured telephony OUI.
Use the Telephony OUI Interface page to add an interface to the voice VLAN on the basis of
the OUI identifier and to configure the OUI QoS mode of voice VLAN.
To configure Telephony OUI on an interface:
STEP 1 Click VLAN Management > Voice VLAN > Telephony OUI Interface.
The Telephony OUI Interface page contains voice VLAN OUI parameters for all interfaces.
STEP 2 To configure an interface to be a candidate port of the telephony OUI-based voice VLAN,
click Edit.
STEP 3 Enter the values for the following fields:
• Interface—Select an interface.
