Smart Network Application (SNA)
Right-Hand Information Panel
482 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
25
The following information is displayed for backbone devices:
Parameter
Name
Notes Example
Product Name From the device description MIB.
This field only appears when the device
is a switch with partial or full SNA
capabilities.
SG500-52P - 52-Port
Gigabit PoE Stackable
Managed Switch
Host Name String of maximum 58 characters RND_1
IP Address Displays the IP address used by SNA to
connect to the device. Additional
advertised existing addresses (IPv4 and
IPv6) can be seen by pressing the icon
next to the label.
192.168.1.55
923:a8bc::234
MAC Address The base MAC address of the device 00:00:b0:83:1f:ac
Description Editable field of up to 80 characters.
Saved on SNA storage.
SNA Support Possible values:
• Full Support for SNA devices
• Partial Support for managed
devices
• No SNA support for unmanaged
devices
This parameter appears only for
switches.
The parameters below only appear when View all is clicked. This option is only
available if the device is a switch with partial or full SNA capabilities.
Existing
VLANs
A list of the VLANs created on the
device. Dashed lines are used to join
consecutive VLANs.
1, 6, 13-19, 1054, 2012-
2100, 4094
Active
Firmware
Version
The version number of the active
firmware
2.2.0.53
