CMA tab on width-adjustment slider and end of
stationary outer slide rail
3CMA tab on arm farthest from server and end of
stationary outer slide rail
1
Rear of server4CMA tab on arm closest to the server and end of
inner slide rail attached to server
2
Cisco SNS 3500 Series Appliance Hardware Installation Guide
24
Install the Cisco SNS 3515 and Cisco SNS 3595 Hardware Appliances
Install the Cisco SNS 3515 or 3595 Appliance in a Rack
