Configuring the Network
Basic Setup
Cisco SPA100Series Administration Guide 26
3
co-exist with NAT, some form of NAT traversal is required, either on the ATA
or another network device. Use this option if your ATA connects to one
network on the WAN port (10.0.0.0 for example) and to another network on
the LAN port (192.168.0.0 for example). This option is selected by default
and is suitable for most deployments.
• Bridge: Bridged mode is used if the ATA is acting as a bridge device to
another router. Choose this option if your ATA bridges a network (10.0.0.0 for
example) to its LAN port (with connected devices also in the 10.0.0x range).
Internet Settings
Use the Network Setup > Basic Setup > Internet Settings page to set up your
Internet connection.
Enter the settings as described in the table. After making changes, click Submit to
save your settings, or click Cancel to redisplay the page with the saved settings.
Internet Connection Type
Field Description
Connection Type Specify the Internet addressing method that your ISP
requires. Default setting: Automatic Configuration -
DHCP
• Automatic Configuration - DHCP: Use this
setting if your ISP dynamically provides an IP
address. No additional settings are required on
this page.
• Static IP: Use this setting if your ISP assigned a
static/permanent IP address. Complete the fields
that appear. See more information below.
• PPPoE (DSL service): Some DSL-based ISPs
use PPPoE (Point-to-Point Protocol over Ethernet)
to establish Internet connections. If you are
connected to the Internet through a DSL line,
check with your ISP to see if they use PPPoE.
Complete the fields that appear. See more
information below.
