Cisco SPA112 Administration Guide

Configuring the Voice Settings
Information
Cisco SPA100Series Administration Guide 47
4
Call 1 and 2 Type The direction of the call. May take one of the following
values:
• PSTN Gateway Call = VoIP-To-PSTN Call
• VoIP Gateway Call = PSTN-To-VoIP Call
• PSTN To Line 1 = PSTN call ring through and
answered by Line 1
• Line 1 Forward to PSTN Gateway = VoIP calls Line 1
then forwarded to PSTN GW
• Line 1 Forward to PSTN Number =VoIP calls Line 1
then forwarded to PSTN number
• Line 1 To PSTN Gateway
• Line 1 Fallback To PSTN Gateway
Call 1 and 2
Remote Hold
Indicates whether the far end has placed the call on hold.
Call 1 and 2
Callback
Indicates whether the call was triggered by a call back
request.
Call 1 and 2 Peer
Name
The name of the peer phone.
Call 1 and 2 Peer
Phone
The phone number of the peer phone.
Call 1 and 2 Call
Duration
The duration of the call.
Call 1 and 2
Packets Sent
The number of packets sent
Call 1 and 2
Packets Recv
The number of packets received.
Call 1 and 2 Bytes
Sent
The number of bytes sent.
Call 1 and 2 Bytes
Recv
The number of bytes received.
Field Description

Cisco SPA112 Specifications

General

Supported network protocols	IPv4, IPv6, ARP, DNS, SRV, DHCP, PPPoE, ICMP, TCP, UDP, RTP, RTCP, SNTP
DHCP client	Yes
VPN support	802.1p
Security algorithms	SSL/TLS
Authentication method	SIP
Modem (RJ-11) ports	2
Ethernet LAN (RJ-45) ports	1
Voice codecs	G.711, G.726, G.729
Certification	FCC, CE, ICES, A-Tick, RoHS, UL
Fax compatibility	T.38
Output current	2 A
Output voltage	5 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	101 mm
Height	28 mm
Weight	153 g
